PreSonus Studio 24c

Studio-grade audio fidelity

Zero cut-backs on definition. Recording and set up with the 26C is easy but this doesn't mean that Presonus have skimped on quality. The Presonus 26C records at 24-bit, 192 kHz resolution. This gives you the best possible recording definition available at this price point. The Presonus XMAX Class A mic preamps offer best in class hardware recording quality, so what goes in, is as good as possible. Presonus' sound is clean, it's clear and it's ultra high definition.



Quick, USB connectivity

Get straight to work. The Presonus 26C uses USB-C connectivity to help you get the quickest possible speeds across a wide variety of devices. USB-C is faster than other USB based devices and can help decrease the levels of input latency you might find with other forms of connectivity. It's fast and innovative and ensures you're getting the best possible accuracy when recording instruments or using a MIDI input device.



Ideal for musicians, DJs and podcasters

The Studio 26C is ideal for a range of applications from capturing studio-grade recordings to podcasting and DJing. The interface comes equipped with two mic/line/instrument inputs (complete with XMAX preamps) delivering an ultra-wide frequency response.



Setting it apart from the 24C, the 26C features Cue Mix A/B functionality. This allows you to switch between two mixes whilst monitoring through headphones. This function is great for musicians, allowing you to audition mixes in real-time. Four DC-coupled line outputs are also included, which can be used for sending CV signals.



Rugged and portable design

The 26C recording interface is perfect for using as a portable studio. It is lightweight and small enough to fit in your bag with your laptop and even a couple of microphones. If there is somewhere outside of your typical recording environment that you need to record, then trust in Presonus to deliver a tough, rugged interface that records whenever, wherever. The clean, modern design gives the Studio 26C a really nice industrial look and thanks to how easy it is to set up, you'll be up and ready to record in minutes, no matter where you are.



Features

USB-C audio interfaces for Mac and Windows PC

Two mic/line/instrument inputs

Record at up to 24-bit, 192 kHz resolution

Updated versions of the original PreSonus Studio-series audio interfaces, including:

USB-C connector (backward compatible with USB 2.0 and 2.0 connections)

Beautiful, modern industrial design

PreSonus XMAX Class A mic preamps

1x1 MIDI In/Out for connecting a keyboard, sound module, or control surface

Four DC-coupled line outputs for control voltages

Cue Mix A/B function allows you to toggle between two mixes while monitoring through headphones

PreSonus Studio One Artist DAW software (macOS/Windows) and 6+ GB of third-party resources

Studio Magic Plug-in Suite plug-in bundle (VST, AU, and AAX formats)

Professional-quality 24-bit, 192 kHz converters for clear, clean, ultra-high-def sound

Global +48V phantom power for condenser microphones

Power-efficient PreSonus XMAX-L Class A solid-state mic preamps

Includes Ableton Live Lite

Specifications

General

Sample Rates: 44.1, 48, 88.2, 96, 176.4, or 192 kHz

Converter Resolution: 24 bit

Converter Dynamic Range: 114 dB

Converter Dynamic Range: 114 dB

Microphone Inputs

Maximum Level: +4.5 dBu (balanced, min gain)

Gain Range: 70 dB

Frequency Response: 20 Hz - 20 kHz (±0.1 dB, min gain, 48 kHz)

Dynamic Range: 110 dB (A-wtd, min gain)

THD + N: 0.004 percent (1 kHz, -1 dBFS, unity gain)

EIN: -125 dBu (max gain, 150Ω, A-wtd)

Input Impedance: 1.6 kΩ

Phantom Power: +48 VDC (10 mA total)

Line Inputs

Maximum Level: +19.5 dBu (balanced, min gain)

Gain Range: 70 dB

Frequency Response: 20 Hz - 20 kHz (±0.1 dB, min gain, 48 kHz)

Dynamic Range: 110 dB (A-wtd, min gain)

THD + N: 0.007 percent (1 kHz, -1 dBFS, min gain)

Input Impedance: 10 kΩ

Instrument Inputs

Maximum Level: +14 dBu (unbalanced, min gain)

Gain Range: 70 dB

Frequency Response: 20 Hz - 20 kHz (±0.15 dB, 48 kHz, min gain)

Dynamic Range:110 dB (A-wtd, min gain)

THD + N: 0.008 percent (1 kHz, -1 dBFS, min gain)

Input Impedance: 1 MΩ

Line Outputs (Mains)

Type: ¼" TRS Female, DC Coupled*

Maximum Level: +10 dBu (balanced)

Frequency Response: 20 Hz - 20 kHz (±0.1 dB, unity gain, 48 kHz)

Dynamic Range: 108 dB (A-wtd)

THD + N: 0.0015 percent (1 kHz, -1 dBFS)

Line Outputs (3/4)

Type: ¼" TRS Female, DC Coupled*

Maximum Level: +10 dBu (balanced)

Frequency Response: 20 Hz - 20 kHz (±0.1dB, unity gain, 48 kHz)

Dynamic Range 113 dB (A-wtd)

THD + N: 0.008 percent (1 kHz, -1 dBFS)

Headphone Outputs

Maximum Power: 30 mW/channel (56Ω load)

Frequency Response: 20 Hz - 20 kHz (±0.2 dB, 56Ω load, 48 kHz)

Dynamic Range: 104 dB (A-wtd, 56Ω load)

THD + N: 0.009 percent (1 kHz, -1 dBFS, no load)

Impedance Working Range: 32Ω to 300Ω

Physical

Dimensions (HxWxD): 1.75" (44 mm) x 7" (180 mm) x 5.5" (144 mm)

Weight: 0.7kg (1.6lbs.)

Product Code: Studio 26C
